Customize Balloon Development

Online balloon design for minimally invasive balloons including angioplasty, valvuloplasty, compliant, non-compliant, semi compliant balloons and custom designs.

Step 1 – Determine your balloon shape requirements

Balloon Shape*
Standard ShapeCustom Shape

Accepted file types: pdf, xls, doc, ppt, jpg, gif, png.

Step 2 – Tell us more about your technical balloon requirements

Balloon Dimensional Requirements

Unit conversion: 1 mil = 0.001” = 0.0254mm 1 Atm = 0.1013 MPa = 14.7 PSI

Balloon OD (A)*

Working Surface (B)*

Total Length (C)

Proximal Cone Length (D)

Distal Cone Length (D)

Proximal Cone Angle (F)*

Distal Cone Angle (G)*

DWT (Double Wall Thickness)

Double Wall Thickness: Wall Thickness x 2.

Indicate Delivery System/Shaft size compatibility or Balloon Neck Size

Delivery System or Balloon Neck*

Delivery System/Shaft Size CompatibilityBalloon Neck Requirements

Balloon Neck Requirements

Proximal Neck Outer Diameter (I)*

Proximal Neck Internal Diameter (H)*

Distal Neck Outer Diameter (L)*

Distal Neck Internal Diameter (K)*

Proximal Neck Length (J)*

Distal Neck Length (M)*

Material

Material *

Balloon Performance Requirements

RBP @ 95/99.9% Confidence & Reliability*

This is the minimum rated burst pressure of the balloon.

Average Burst Pressure

This is an average burst pressure not a rated pressure.

Nominal Pressure*

Compliance*

Special Requirements

e.g. materials, specification, matrix of sizes required

Step 3 – Tell us about you & your balloon project

Contact Name*

First

Last

Company*

Country*

Email Address*

Balloon application/description

Desired lead time
